    NANO2 Quick Acting Subminiature Surface Mount Brick Ceramic Fuse 2A 250V 10.2mmx3.2mm

    Ask Lasest Price
    Model Number : R1032.1200
    Certification : UL,cUL
    Price : Negotiable
    Payment Terms : T/T, Western Union
    Supply Ability : 20,000,000 Pieces Per Month
    Delivery Time : 1-2 Weeks
    • Product Details
    • Company Profile

    NANO2 Quick Acting Subminiature Surface Mount Brick Ceramic Fuse 2A 250V 10.2mmx3.2mm


    NANO2 Gold Sliver Plated Quick Acting Subminiature Surface Mount Brick Ceramic Fuse 2A 250V 10.2mmx3.2mm


    Description


    The 250 NANO2 Fuse is a small square surface mount fuse that is designed to support higher voltage space sensitive applications. Enables compliance with the RoHS directive and is fully compatible with lead-free solder alloy and higher temperature profiles associated with lead-free assembly.


    Features

    • 250 VAC voltage rating
    • Fast-acting Fuse
    • Available 0.50A – 5.00A
    • RoHS Compliant
    • Fully compatible with lead-free solder alloys and higher temperature profiles associated with lead-free assembly
    Application
    • AC/DC power adaptor
    • Telecom equipment system power
    • Portable system built-in AC/DC converter
    • Lighting System
    • LED Lighting

    Specification



    Material


    End cap

    Au Plated Brass Cap

    Body

    Non-Transparent Square Ceramic Tube

    Fuse element

    Cu-Ag Alloy wire


    Package


    24mm Tape and Reel

    EIA-RS 481-2 (IEC 286, part 3)

    2000pcs per reel


    Reliability Test


    NO.ItemContentReference standards
    1

    Operating Temperature

    -55°C to 125°C

    IEC60068-2-1/2

    2

    Solderability

    T=240°C±5°C , t=3sec±0.5sec,Coverage≥95%

    MIL-STD-202, Method 208

    3

    Resistance to Soldering Heat

    10 sec at 260°C

    MIL-STD-202, Method 210, Test condition B

    4

    Insulation Resistance (after Opening)

    10,000 ohms minimum

    MIL-STD-202, Method 302, Test Condition A

    5

    Thermal Shock

    5 cycles, -65°C / +125°C, 15 minutes at each extreme

    MIL-STD-202, Method 107, Test Condition B

    6

    Mechanical Shock

    100G’s peak for 6 milliseconds,3cycles

    MIL-STD-202, Method 213, Test I

    7

    Vibration

    0.03”amplitude, 10-55 Hz in 1 min. 2hrs each XYZ=6hrs

    MIL-STD-202, Method 201

    8

    Moisture Resistance

    10 cycles

    MIL-STD-202, Method 106

    9

    Salt Spray

    5% salt solution, 48hrs

    MIL-STD-202, Method 101, Test

    Condition B


    Electrical Characteristics


    Test Condition : All electrical test is to be conducted with the ambient air at a temperature of 25±5℃.

    Interrupting Rating:Breaking Capacity: 50A@250Vac,200A@125Vac.

    Operating Characteristics

    Current Range

    % of Ampere Rating(In)

    Melting Time
    0.05A-15A/20A-60A

    100% * In

    >4 Hour
    0.05A-15A/20A-60A

    200% * In

    <60 sec
