    95% Relative Humidity Modular DC Surge Protection Device 30kA 48V

    Ask Lasest Price
    Brand Name : Uchi
    Model Number : DC Surge Protection Device
    Certification : CE / SGS / ISO900
    Price : Negotiate Ex-work / FOB price
    Payment Terms : TT / LC
    Supply Ability : 100000 Piece/Pieces Month
    Delivery Time : Shipped in 10 days after payment
    • Product Details
    • Company Profile

    95% Relative Humidity Modular DC Surge Protection Device 30kA 48V

    95% Relative Humidity 30kA 48V Modular DC Surge Protection Device

    Performance characteristics:


    Adopt the latest thermal separation technology, built-in thermal protection, automatic separation device for short-circuit failure, completely avoid fire;The core components adopt internationally well-known brands, with excellent performance, stable and reliable work;

    • Relative humidity: ≤ 95%;
    • Atmospheric Pressure: 70kPa~106kPa
    • Degree of protection according to IEC/EN60529: IP20.

    The main parameters:


    Operating Voltage : 48V DC

    Nominal discharge current In(8/20μs): 15kA
    Maximum discharge current Imax (8/20μs):30kA
    Combination method: +/PE,-/PE
    Response time: ≤25ns
    Working environment: -40℃~+80℃
    Installation method: rail installation


    Place of Origin: Dongguan


    Qualification certification: CE, FCC, ROHS, product test report, Pacific Product Insurance, etc.
    Test standard: IEC 61643-1:2005; GB 18802.1-2011 Low Voltage Surge Protector (SPD) Part 1 Surge Protector for Low Voltage Distribution System-Performance Requirements and Test Methods

    Scope of application:
    This product is a special lightning surge protector for DC systems, suitable for 12V DC power supply systems.


    DC Surge Protection Device
    SPD classification according to EN61643-11Type 2
    Applicable Power Supply SystemDC Power Supply System
    Nominal voltage UnDC 48V
    Max. continuous operating voltage UcDC 65V
    Nominal discharge current (8/20us) In15kA
    Maximum Discharge Current (8/20µs) Imax30kA
    Voltage protection level Up≤300V
    Protection mode(s)CM
    Operating temperature range Tu-40℃-80℃
    Relative Humidity≤95%RH
    Operating state / fault indicationgreen / red
    Cross-section area (Min.)2.5mm2
    Cross-section area (Max.)16mm2
    Protection Mode"+"-PE, "-"-PE
    For mounting on35mm Din rail
    Enclosure materialThermal plastic UL94-V0
    Degree of protectionIP20
    Remote Alarm FunctionOptional

    More application


    • Low voltage DC power supply SPD has products with nominal operating voltage of 48V.
    • Plug-in Protection Module. Easily Installation and Maintenance.
    • Over temperature protection.
    • Din Rail Mounting.


    FAQ


    Q: Can I get some samples?
    A: Yes, Sample orders welcomed.

    Q: Can I use my own Logo or design on goods?
    A: Yes, Customized logo and design on mass production are available.

    Q:What is the delivery time?
    A: 3 days for samples, 7-15 days for mass production.

    Q: What is the payment term?
    A: T/T, L/C at sight, West union , Paypal, etc.
